For over 30 years, Weizhong Revolving Machinery has delivered large-scale rotational solutions to global logistics operators and facility managers. Our heavy-duty vans turntable eliminates dangerous reversing maneuvers in narrow urban alleys and crowded loading docks, cutting vehicle turnaround time by 70% and reducing accident-related downtime. Engineered for small commercial vans and heavy trucks up to 100 tons, it sets the industry standard for high-density urban logistics and modern warehouse management.
360° full rotation in seconds eliminates long-distance backward driving, reducing per-vehicle loading time from 15 minutes to 3 minutes. This allows your fleet to complete 2× more daily deliveries without expanding your vehicle count.
No more blind-spot collisions or property damage in tight spaces, lowering insurance premiums and worker compensation costs. Our system ensures vehicles always exit forward, eliminating the single biggest cause of loading dock injuries.
Compact design fits in narrow alleys and small bays, eliminating the need for large turning radii. This frees up critical space for additional storage bays or loading zones in high-rent urban locations.
Standard Sweden Tele-Radio remote control allows drivers to operate the turntable from a safe distance. No additional ground staff required, reducing labor costs and minimizing workplace hazards.
Unlike traditional gear systems that suffer from rapid wear and excessive vibration, our proprietary patented Pin-Gear Drive delivers unmatched performance for commercial operations:
Smooth, vibration-free rotation that protects sensitive electronic and fragile cargo
Low-noise operation (≤65dB) compliant with urban residential area regulations
2× longer service life compared to conventional chain-driven turntables
Minimal maintenance requirements, reducing annual operating costs by 40%
All turntables feature a modular steel structure with hot-dipped galvanized coatings and rust-resistant primers, providing reliable corrosion resistance for outdoor urban installations in all weather conditions.
Diameter |
Loading Capacity |
Rotating Speed |
Motor Power |
|---|---|---|---|
9m |
30 Tons |
0.1-0.5 RPM |
4.0 KW |
12m |
40 Tons |
0.1-0.5 RPM |
11 KW |
15m |
60 Tons |
0.1-0.5 RPM |
18.5 KW |
18m |
80 Tons |
0.1-0.25 RPM |
15 KW |
24m |
100 Tons |
0.1-0.25 RPM |
22 KW |
Common Specifications:
Power Supply: 3 Phase 380V AC - 480V AC
Top Surface Options: Diamond Tread Steel Plate (6mm-8mm) / Plywood (18mm) / Aluminum Alloy
Perfect for narrow alleys and small loading bays in city centers, enabling instant U-turns at the point of delivery. Ideal for courier companies and parcel distribution networks operating in dense metropolitan areas.
Maximizes usable space by eliminating large turning areas, increasing storage capacity by up to 25%. Suitable for e-commerce fulfillment centers and third-party logistics facilities.
Low-noise operation allows 24/7 delivery access without disturbing residents. Compliant with local noise ordinances, making it ideal for mixed-use buildings and urban residential complexes.
Handles heavy construction vehicles and materials, improving site logistics efficiency and safety. Designed to withstand harsh construction site conditions and heavy daily use.
30+ years of industry leadership in large-scale rotational solutions
Global after-sales support network covering 30+ countries
Modular design for rapid on-site assembly (standard installation: 4-8 hours)
Customization available for oversized vehicles and special requirements
All products undergo rigorous load testing before delivery
2-year standard warranty with extended coverage options
Yes. While optimized for commercial vans, our models support loads up to 100 tons. We can also customize diameter and load capacity for oversized vehicles and specialized applications.
Absolutely. All outdoor models feature hot-dipped galvanized steel coatings and rust-resistant primers, withstanding rain, snow, and extreme temperatures ranging from -30°C to 60°C.
Our modular design allows for rapid assembly. A standard urban installation takes 4-8 hours, depending on site preparation. Our technical team provides full on-site support during installation.
The Pin-Gear Drive system requires minimal maintenance. We recommend a visual inspection every 6 months and lubrication once per year. Full maintenance schedules are included with every purchase.
